‧Latch: 3 hours fire rating certified. UL File No. R15047
• One Side Deadlock • US3 / US5 / US15 / US26D / US32 / US32D /12P‧Door Thickness: 1-3/8" to 1-3/4"(35mm~45mm) standard. 2" (51mm) optional.
‧Backset: Fits both 2-3/8" and 2-3/4" (60mm and 70mm).
‧Latch: 2-3/8"(60mm) or 2-3/4"(70mm) adjustable latch. 6-way latch also available. Steel latch bolt with hardened steel rod insert, Full 1" (25.4mm) throw.
‧cylinder: 5 pin Kwikset keyway standard. 6 pin cylinder optional. Solid brass or zinc alloy cylinder housing also available.
