Tong Lung Metal Industry Co., LTD

Door Thickness
Fits 1-5/8” to 1-3/4”

Backset
Fits both 2-3/8” or 2-3/4” (60mm or 70mm)

Exposed Trim
Stainless steel or zinc alloy

Strike
Deadbolt: Full lip 1-3/4”x2-1/4”(9117)
Latch Bolt: Standard Full lip 1-3/4”x2-1/4”round corner(9103)

Door Prep
5- 1/2” Center to center (standard)

Latch
Deadbolt: 2-3/8" and 2-3/4" adjustable
Bolt: Steel with hardened steel rod insert
Faceplate: 1" X 2-1/4" round corner
Latch Bolt: 2-3/8" or 2-3/4" adjustable
Bolt: 1/2" throw, stainless steel
Faceplate: 1" X 2-1/4" round corner

Cylinder
KW1 standard
SC1 and SC4 optional

Door Handing
Handed levers (specify when ordering)

Finishes
US3,US5,US10B,US15,US26,US26D,12P
